| Manufacturer | Weight (lbs) | Length (to rear seal) | Mount Location from Front of Case |
| General Motors | |||
| Powerglide (long shaft) (Chevrolet, fit-all) | 97 | 27.6" | 20.6" |
| 200C (all) (Chevrolet, BOP) | 96 | 27.7" | |
| 200-4R (all) (BOP, fit-all) | 132 | 27.7" | 27" |
| 350 (6 inch tail shaft) (Chevrolet, BOP, fit-all) | 122 | 27.7" | 20.4" |
| 700R-4 (exc. corvette) (Chevrolet) | 30.6"-30.8" | 22.5" | |
| 4L60E (exc. corvette & LS1) (Chevrolet) | 30.6"-30.8" | 23.2" | |
| 400 (short tail shaft) | 130 | 28.3"-28.4" | 26.9" |
| 4L80E (std. 2WD) (Chevrolet) | 32.7" | 30.4" | |
| Ford | |||
| C6 (all) | 33.5" | 22.4" | |
| C4 (pan fill) (case fill) | 24.3" 30.6" | 19.5" 20.5" | |
| AOD (small block) | 30.4" | 22.3" | |
| AODE/4R70W (small block, modular) | 31.2" | 23.3" | |
| Chrysler | |||
| A-727/37RH (small block) (big block) | 34.4" 34.5" | 23.8" 22.8" | |
| A-904 /32RH (small block) | 30.8" | 23" | |
| A-500/42RH/42RE (small block) | 37" | 24.5" | |
